Size

DN40-DN800

Nominal Pressure

PN10/16, 150-300LB

Working Temperature

-30^。c - 135^。C

Suitable Media

Chemicals, air, water, steam, oil, acids, salts etc.

Face to Face

DIN3202-F6

Flange drilling

 DIN2501 PN10/16, ANSI 125/150, BS4504, JIS10K,EN1092

Test Inspection

 API598,DN3230

 Body

 Ductile Iron

 Disc

Steel +NBR/EPDM

 Bonnet

 Ductile Iron

Bonnet Gasket

 NBR/EPDM

Bolts/Nuts

 Stainless Steel
